Assembly Instructions

Sit in your kayak and make paddle motions with your arms. Measure the distance from the center of your seat opening to the end of your paddling arm motion. That spot is the front of the aluminum holder bracket that mounts to the kayak. Set the two aluminum brackets in place on the top of the kayak and mark the two holes in each bracket. Using a #36 drill bit drill two marked holes in each bracket. Place the brackets on top of the kayak and using the 4 screws provided seat the screws through the holes in the aluminum bracket until tight. Place one plastic holder into the aluminum bracket and slide the 1⁄4” pin through the holes in the aluminum bracket and the plastic holder. Now bend the Kybrella so to place the second plastic holder into the aluminum bracket and repeat the operation. Now pull the first plastic cover rod up until it stops going forward by hitting the front of the plastic holder. Now slide the 3/16” pin through the plastic holder and through the first cover rod. Now you are ready to enjoy your Kybrella.
care and washing instructions: soap and water, no bleach, air dry
WARRANTY: 1 year from purchase on structural parts. the manufacture recommends removal of Kybrella canopy during transportation to prevent potential damage.
KYBRELLA LLC IS NOT RESPONSIBLE FOR INJURIES INCURRED. MAKE SURE TO FOLLOW ALL ASSEMBLY INSTRUCTIONS PROPERLY.
